ELECTRONICS-SALON Bistable DPDT 8 Amp Relay Module, DC24V Coil, with DIN Rail Carrier Housing
Product details
| Management number | 221601539 | Release Date | 2026/05/03 | List Price | US$9.60 | Model Number | 221601539 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Bistable/Latching DPDT 8 Amp Power Relay Module, with High Quality Carrier Housing for DIN rail mounting. Model number: MD-D151/24V-B. This item has been assembled, and electrical test passed. RT424F24 high quality bistable relay. Din rail mountable - for width 35 / 32 / 15mm rails. BC517 Darlington transistor driving relay, Improve the reliability of action. High quantity terminal blocks, easy connection wires. FR-4 Fiber glass PCB. Typical applications: Battery powered equipment or applications with “memory function”. Operating voltage: DC 24V. Input control signal voltage: Low level: 0 to 0.5V High level: 2.5 to 24V Relay contact rating: Contact arrangement: DPDT (2 form C) Rated voltage: 250VAC Rated current: 8A, UL 10A Breaking capacity max.: 2000VA
- Bistable/Latching DPDT 8 Amp Power Relay Module, with High Quality Carrier Housing for DIN rail mounting.
- This item has been assembled, and electrical test passed.
- Din rail mountable - for width 35 / 32 / 15mm rails.
- Typical applications: Battery powered equipment or applications with “memory function”.
- RT424F24 high quality bistable relay.
| Wattage | 192 watts |
|---|---|
| Brand Name | Electronics-Salon |
| Part Number | MD-D151T/24V-1 |
| Coil Voltage | 24 Volts |
| Contact Type | Dpdt |
| Manufacturer | Electronics-Salon |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 8 Amps |
| Operation Mode | Electrical |
| Contact Material | Silver Alloy |
| Specification Met | UL |
| Contact Current Rating | 8 Amps |
| Maximum Switching Current | 8 Amps |
| Maximum Switching Voltage | 24 Volts |
